SmarTek Systems Cabinet Interfaces
Sensing and Systems Integration Solutions
USI RPU
The SmarTek Systems Universal Sensor Interface (USI) is a low cost and rugged programmable processor used as a custom interface between various remote sensors or systems (traffic sensors, traffic counters, weather stations, temperature and pavement sensors, etc.). The USI can also be used as a low cost stand alone cabinet RPU.
The USI requires little power and has a very small foot print. The USI includes a Maxim "One Wire" Micro-Lan Interface and hence, may be used as a flexible custom interface for variety of devices that don't have an RS-232 interface (relays, switches, temperature probes, etc.).
Features and Specifications
- Size ... 5.5 in W x 5.5 in D x 1.5 in H
- Shelf Mount, Metal Enclosure
- Operating Temperature ... -40 deg C to 70 deg C
- Humidity ... 5-95%, non-condensing
- SRAM ... 512 K Bytes Battery Backed
- Flash ... 256 K Bytes
- Two Serial Ports ... AUX with no handshaking, SYS with handshaking
- Display ... Ten front panel LEDs for visible alarm/operational status.
- Power ... 9 to 24 VDC, less than 1.0 Watts
- Clock ... Battery-Backed Real Time Clock
- Reset Switch on Front Panel
- Six Opto-Isolated Output Relays on Back Panel Connector
- Maxim "One Wire" Micro-Lan Interface on Back Panel Connector
The SmarTek Systems Universal Sensor Interface (USI) is a low cost and rugged programmable processor used as a custom interface between various remote sensors or systems (traffic sensors, traffic counters, weather stations, temperature and pavement sensors, etc.). The USI can also be used as a low cost stand alone cabinet RPU.
The USI requires little power and has a very small foot print. The USI includes a Maxim "One Wire" Micro-Lan Interface and hence, may be used as a flexible custom interface for variety of devices that don't have an RS-232 interface (relays, switches, temperature probes, etc.).
Features and Specifications
- Size ... 5.5 in W x 5.5 in D x 1.5 in H
- Shelf Mount, Metal Enclosure
- Operating Temperature ... -40 deg C to 70 deg C
- Humidity ... 5-95%, non-condensing
- SRAM ... 512 K Bytes Battery Backed
- Flash ... 256 K Bytes
- Two Serial Ports ... AUX with no handshaking, SYS with handshaking
- Display ... Ten front panel LEDs for visible alarm/operational status.
- Power ... 9 to 24 VDC, less than 1.0 Watts
- Clock ... Battery-Backed Real Time Clock
- Reset Switch on Front Panel
- Six Opto-Isolated Output Relays on Back Panel Connector
- Maxim "One Wire" Micro-Lan Interface on Back Panel Connector
BL-2030
The SmarTek Systems, Inc. STS-BL2030 is a low cost and rugged programmable processor used as a custom interface between various remote sensors (loop detectors, traffic, weather, temperature, etc.) and a standardized Remote Processing Unit (RPU) or for use as a stand alone RPU.
The STS-BL2030 requires little power and has a very small foot print. The STS-BL2030 may also be used as a flexible custom interface for loop detectors and other devices without a serial data stream.
Features and Specifications
- Size ... 4.9 in W x 5.6 in D x 1.1 in H
- Shelf mount, high impact black plastic enclosure
- Operating Temperature ... -40 deg C to 70 deg C
- Humidity ... 5-95%, non-condensing
- SRAM ... 128 K Bytes and Flash ... 256 K Bytes
- Serial Ports 3 total: 2 with handshaking and 1 without
- 7 Dual-Purpose Analog or Digital Inputs, 10-bit resolution, 0-48 V DC
- 1 Relay Output SPDT, 1 A @ 30 V DC, 0.3 A @ 120 V AC
- 1 Activity LED
- Power ... 9 to 40 VDC, less than 1.5 Watts
- Clock ... Battery-Backed Real Time Clock
The SmarTek Systems, Inc. STS-BL2030 is a low cost and rugged programmable processor used as a custom interface between various remote sensors (loop detectors, traffic, weather, temperature, etc.) and a standardized Remote Processing Unit (RPU) or for use as a stand alone RPU.
The STS-BL2030 requires little power and has a very small foot print. The STS-BL2030 may also be used as a flexible custom interface for loop detectors and other devices without a serial data stream.
Features and Specifications
- Size ... 4.9 in W x 5.6 in D x 1.1 in H
- Shelf mount, high impact black plastic enclosure
- Operating Temperature ... -40 deg C to 70 deg C
- Humidity ... 5-95%, non-condensing
- SRAM ... 128 K Bytes and Flash ... 256 K Bytes
- Serial Ports 3 total: 2 with handshaking and 1 without
- 7 Dual-Purpose Analog or Digital Inputs, 10-bit resolution, 0-48 V DC
- 1 Relay Output SPDT, 1 A @ 30 V DC, 0.3 A @ 120 V AC
- 1 Activity LED
- Power ... 9 to 40 VDC, less than 1.5 Watts
- Clock ... Battery-Backed Real Time Clock
BL-2030 Processing Unit
USI- Remote Processing Unit
